PDDL Design – the new RoboCLuedo PDDL model

Warning

This document is very old, and for sure it needs to be updated. You can find the current model in the folder /robocluedo_rosplan/pddl/robocluedo_3.

I leave this document here because it contains the very first design process of the current PDDL, which is changed a lot during the development of the project. Here are the basic principles.

Todo

a big half of this document is still in italian. Remember to translate it.

Contents

PDDL Design – the new RoboCLuedo PDDL model

Differences from the previous version

see the previous version of the RoboCLuedo #2 Project

usage of landmarks instead of only one goal

a landmark is a sort of checkpoint, and in particular it will correspond to a particular phase of the mission. The AI will will work on two levels: the highest one, the mission level, will decide how to combine landmarks in order to let the mission succeed, whereas the lowest one, implemented using rosplan, plans how to carry out the single action depending on the current status of the robot.

For instance, the mission manager could say “COLLECT A HINT”, leavng the planner the task to decide precisely which sequence of actions the robot has to take in order to fulfill the current mission objective.
the PDDL just manages the movements and how the robot works, and not other informations. Clear distinction between the KB os ROSPlan and the aRMOR KB

in the previous version of the model, the rosplan KB has been used also as a common KB for the reasoning. This requires to declare predicates inside the PDDL domain, and to decide how to combine two sets of informations. It is a very poor design choice, which lets to a overcomplicated implementation. It is simpler to separate the true reasoning from the simple problem solving.
a simpler, concise model: this increases the flexibility of the model, and in particular it makes quicker any future update of the arch
much more like a stata machine than the previous version
no usage of fluents

in this case, using fluents is not so important. In order to keep as simpler as possible the declaration of the problem, it is better to rely only on the simple predicates.

A list of Landmarks

Note

the implementation of the landmarks is a bit more cumbersome, even if the principle is the one outlined here. See kb_interface for more informations.

Here are the macro-objectives the mission planner could require to the ROSPlan unit:

replan preconditions:
```
(dirty )
```
goal:
```
(not-dirty )
```
propose a solution – solve preconditions:
```
(not-dirty )
```
goal:
```
(dirty )
```

collect a new hint – collect preconditions:

(not-dirty )

goal:

(not-dirty )
(hint-collected ?wp )

list of actions

Note

This document reports the very first version of the code, which is sometimes not correct. Please refer to the models inside the folder /robocluedo_rosplan/pddl/robocluedo_3.

Note

document in italian (thinking in english makes everything … annoyingly slower)

REPLAN

(ACTION) replan
- c’è un bool (dirty ) che indica quando il sistema non è inizializzato
- questa azione serve solo per “resettare” la KB di rosplan
- per l’aggiornamento, la action usa il nodo KB interface che si occuperà di lettura e scrittura nella kb di rosplan

azione PDDL:

(:durative-action replan
	:parameters ( )
	:duration (= ?duration 0.99 )
	:condition (and
		(at start (dirty ))
	)
	:effect (and
		(at end (not (dirty )))
		(at end (not-dirty ))
	)
)

implementazione ROS:

COLLECT

(ACTION) move-to
- semplice azione di movimento da un punto ad un altro
- il sistema è molto simile a quello della vecchia versione se non per qualche predicato di meno
- le posizioni in cui il robot può andare sono quelle non marcate come (is-center ?wp), ovvero usa il not
- il robot non può compiere un’azione di movimento verso lo stesso punto in cui si trova: insomma, deve muoversi
- l’azione si aspetta che qualche altro sistema implementi un servizio a cui l’azione si connette come client per interagire col navigation system
- tale servizio si occupa anche di associare il nome del waypoint alla posizione del waypoint in termini di coordinate cartesiane

azione PDDL:

(:durative-action move-to
	:parameters ( ?from ?to - waypoint )

	:duration (= ?duration 0.99 )

	:condition (and
		;;status
		(at start (not-hint-ready ))
		(at start (not-dirty ))

		;; localization
		(at start (at ?from ))

		;; passage
		(at start (passage ?from ?to ))

		;; path tracking
		(at start (not-explored ?to ))

		;;center conditions
		(at start (not-is-center ?to ))
	)

	:effect (and
		;; localization
		(at start (not (at ?from )))
		(at end (at ?to ))

		;; (in any case)
		(at end (not (at-center )))
		(at end (not-at-center ))

		;; path tracking
		(at start (not (not-explored ?to)))
		(at start (explored ?to))
	)
)

implementazione ROS:

(ACTION) signal-collect-hint
- il robot si prepara a raccogliere l’hint dal marker
- implementato come una simulated action

azione PDDL:

(:durative-action signal-collect-hint
	:parameters ( ?wp - waypoint )

	:duration (= ?duration 0.99 )

	:condition (and
		;; status
		(at start (not-hint-ready ))
		(at start (not-dirty ))

		;; localization
		(at start (at ?wp ))

		;; hint inside
		(at start (not-hint-collected ?wp ))
	)

	:effect (and
		(at start (not (not-hint-ready )))
		(at end (hint-ready ))
	)
)

(ACTION) collect-hint
- l’azione implementa solo il moto del braccio verso il marker: avvicina, rimani fermo, rientra il braccio, e avanti
- in caso si presenterà il bisogno di aggiornare il sistema di raccolta degli hint (ad esempio, detection degli hint tramite una videocamera piuttosto che tramite un sistema di hints) si dovrà cambiare solo questa particolare azione e stop.
- l’azione si aspetta che un altro nodo implementi il servizio che permette all’architettura di interagire con il manipulation controller

azione PDDL:

(:durative-action collect-hint
	:parameters ( ?wp - waypoint )

	:duration (= ?duration 0.99 )

	:condition (and
		;; status
		(at start (hint-ready ))

		;; localization
		(at start (at ?wp ))
		(at start (not-is-center ?wp ))
	)

	:effect (and
		;; status
		(at end (not (hint-ready )))
		(at end (not-hint-ready ))
	)
)

implementazione ROS:

SOLVE

(ACTION) move-to-center
- come precondizione il robot non si trova al centro, quindi la posizione attuale è (not-is-center ?wp)
- al termine dell’azione, il robot è in stato (ready-to-solve )

azione PDDL:

(:durative-action move-to-center
	:parameters ( ?from ?to - waypoint )

	:duration (= ?duration 0.99 )

	:condition (and
		;;status
		(at start (not-hint-ready ))
		(at start (not-dirty ))

		;; localization
		(at start (at ?from ))
		(at start (is-center ?to ))

		;; center conditions
		(at start (not-at-center ))

		;; passage
		(at start (passage ?from ?to ))
	)

	:effect (and
		;; localization
		(at start (not (at ?from )))
		(at end (at ?to ))

		;; in center
		(at start (not (not-at-center )))
		(at end (at-center ))
	)
)

implementazione ROS:

(ACTION) solve
- l’azione PDDL non fa che settare tutto per fare il replan
- a differenza della precedente versione, il PDDL non tiene traccia delle ipotesi (per questo c’è aRMOR)
- arrivato alla solve, il mission manager ricerca e propone la soluzione
- è implementata come una simulated action

azione PDDL:

(:durative-action solve
	:parameters ( )

	:duration (= ?duration 0.99 )

	:condition (and
		;;status
		(at start (not-hint-ready ))
		(at start (at-center ))
		(at start (not-dirty ))

	)

	:effect (and
		(at start (not (not-dirty )))
		(at end (dirty ))
	)
)
